Multiquip LS500

Multiquip LS500 Information

50yd/hr, Deutz BF4L2011F 77hp Turbo Diesel

Filling a niche that has been neglected, the Mayco LS500 Concrete Pump has the versatility to efficiently place 2″ line mixes (3/8″ pea gravel, masonry grout, shotcrete), structural concrete containing up to 1.5″ aggregate, as well as everything in-between. Equipped with 6″ diameter concrete cylinders and utilizing a 36″ stroke ensures that the LS500 will smoothly pump even low slump concrete mix designs.

Concrete piston face pressure of 1100 PSI (76 Bar)
Concrete cylinder diameter is 6 inches (152 mm) with 36-inch stroke (914 mm)
Horizonal pumping distance of 1000 feet (300 meters), vertical is 300 feet (91 meters)
Powered by a 77-hp (57.4 kW) Deutz BF4L2011 turbo diesel
Designed for aggregate sized up to 1-1/2 inches (38 mm)
Hopper remixer/agitator standard
True Reverse allows stroke change during any point in the pumping cycle
Hard faced wear components for longer life
Variable volume output (from the control panel) from 0-to-50 cubic yards (38 cubic meters) per hour
Ideal for use with shotcrete, masonry block fill, slabs, footings, basements, & compaction grouting
Innovative DCP (Digital Control Panel) solid state electronic control box with full diagnostic & performance monitoring
Optional wireless radio remote has a range of 1000 feet (300 meters)
Optional rear hydraulic outriggers
Optional air or electric vibrators for hopper screen
