$50,100

2020 E42 BOBCAT COMPACT EXCAVATOR

Going on right now get 0% for 36 mo. on select used equipment. Offer has been extended - Ends 12/31/24. Eligible on select Skid Steer Loaders, Compact Track Loaders, and Compact Excavators, 2014 and newer models.

The 2020 Bobcat E42 Compact Excavator is a powerful and versatile machine designed to tackle all your excavation tasks with ease. It features a robust engine and an enclosed cab equipped with heating and air conditioning for comfort in any weather. Stay connected with the 7-inch touchscreen display that includes radio and Bluetooth connectivity. Enjoy a smooth ride with the cloth suspension seat and enhanced safety with the travel motion alarm. The long arm offers extended reach, and the clamp with diverter valve adds versatility. The Hydraulic X-Change system allows for quick and effortless attachment changes, increasing your efficiency on the job site. Serial Number: B2VW17406 – Stock Number: 1378360.

Hours: 1569 – Serial Number: B2VW17406 – Stock Number: 1378360

1569.5

Hours

B2VW17406

Serial #

1378360

Stock #

2020 E42 BOBCAT COMPACT EXCAVATOR

Let's Get Started

"*" indicates required fields

This field is hidden when viewing the form
Newsletter Signup
This field is hidden when viewing the form
This field is hidden when viewing the form
This field is hidden when viewing the form
This field is hidden when viewing the form
This field is hidden when viewing the form
This field is hidden when viewing the form
This field is hidden when viewing the form
This field is hidden when viewing the form

Bobcat E42 Compact Excavator Specs & Add-Ons

** Listed specs based on machine base model. Actual specs may vary depending on model and options **

Key Specifications & Add-ons

Air Conditioning Optional
Cab Enclosure Optional
Cab Heater Optional
Heater Air Conditioning Optional
Radio Optional
Tail Swing Type Conventional
Engine Shutdown Standard
Auxiliary Hydraulics Standard
Secondary Auxiliary Hydraulics Optional
Quick Tach System Standard
Rubber Track Standard
Selectable Auxiliary Hydraulic Flow Standard
Angle Blade Optional
Horsepower 42.6 hp
Operating Weight 10,666 lb
Bucket Digging Force 9,601 lbf
Maximum Reach at Ground Level 19.1 ft
Width 72.8 in
Tail Swing Type Conventional
Fuel Tank 19 gal
Auxiliary Std Flow 20 gal/min
Auxiliary Pressure 3,045 psi

Performance

Operating Weight 10,666 lb
Weight Class 4.8 t
Travel Speed - High 3.3 mph
Travel Speed - Low 1.6 mph
Arm Digging Force 5,852 lbf
Bucket Digging Force 9,601 lbf
Rated Lift Capacity 4638 lb
Lift Radius 118 in
Boom Swing - Left 75°
Boom Swing - Right 50°
Maximum Dig Depth 12.4 ft
Max Dump Height 13.7 ft
Maximum Reach at Ground Level 19.1 ft
Emissions Tier (EPA) Tier 4
Engine Fuel Diesel
Maximum Governed RPM 2,200 rpm
Horsepower 42.6 hp
Turbocharged Engine yes
Optional Turbocharged Engine N/A

Dimensions

Length 201.3 in
Overall Length in Travel Position 201.3 in
Width 72.8 in
Height 99.1 in
Height with Operator Cab 99.1 in

Bobcat E42 Compact Excavator Features

Low-Effort Joysticks

Low-Effort Joysticks

Low-effort joysticks in R2-Series excavators respond easily to operator input, helping operators work longer with less fatigue.

Dual Flange Roller System

Dual Flange Roller System

Dual flange track rollers extend the undercarriage structure closer to the track’s edge so you can dig with greater confidence over the side of the machine.

Multiple Arm Configurations

Multiple Arm Configurations

Multiple arm configurations are available on select models, including standard, long and extendable. Depending on the reach, depth, power, and lifting performance you need, there’s an arm to meet your job requirements.

Premium Cab

Premium Cab

Premium comfort gives you the endurance to power through long days and tough jobs. When you step inside the Bobcat compact (mini) excavator cab, you’ll experience plenty of headroom and legroom, clear visibility, a larger suspension seat and more.

Touch Display

Touch Display

The most advanced in-cab display for compact equipment – optional on R2-Series excavators – provides detailed machine information and unprecedented device connectivity. View machine performance information on the wide touchscreen.

Depth Check System

Depth Check System

The Bobcat® depth check system delivers accurate dig depth measurement for precise digging performance, eliminating over-digging and the costs associated with backfilling and compacting fill material. R2-Series models are depth check ready.

Pro Clamp System

Pro Clamp System

The Pro Clamp™ system consists of a base component, standard pin-on work tool and optional grading tool. Grab large, small or irregular objects with greater confidence. Create a smooth trench bottom and clean up spoil piles quickly.

Integrated Lift Eye

Integrated Lift Eye

The lift eye is standard on R2-Series excavators to provide a convenient method for handling objects or moving items in and out of the trench.

Optional Rear Camera

Optional Rear Camera

The optional rear camera for R2-Series excavators provides an additional viewpoint for working in certain applications. When needed, you can get a continuous rear view from the operator seat.
